General Specification
Frame / Impeller: Plastic
Lead Wire: AWG#24 or Equivalent (+)Red, (-)Black
Ball Bearing 50,000Hrs(40°C)
Sleeve Bearing 30,000Hrs(40°C)
Operating temperature: -10°C~+70°C
Storage temperature: -40°C~+70°C
Art. No. | # Bearing Type | Rated Voltage (VDC) | Operating Voltage (VDC) | Input Current (A) | Input Power (W) | Speed (RPM) | Max Air Volum | Max Static Pressure | Noise (dB-A) | Weight (g) | ||
(CFM) | m3/min | Inch-H2O | mm-H2O | |||||||||
DC8015#12L | B.S | 12 | 7.0~13.8 | 0.09 | 1.08 | 2400 | 24.72 | 0.7 | 0.087 | 2.12 | 23 | 54 |
DC8015#12M | B.S | 12 | 7.0~13.8 | 0.11 | 1.32 | 2700 | 27.45 | 0.8 | 0.107 | 2.71 | 27 | 54 |
DC8015#12H | B.S | 12 | 7.0~13.8 | 0.14 | 1.68 | 3100 | 33.55 | 0.95 | 0.138 | 3.5 | 33 | 54 |
DC8015#24L | B.S | 24 | 14.0~27.6 | 0.05 | 1.2 | 2000 | 24.72 | 0.7 | 0.087 | 2.12 | 23 | 54 |
DC8015#24M | B.S | 24 | 14.0~27.6 | 0.06 | 1.44 | 2700 | 27.45 | 0.8 | 0.107 | 2.71 | 27 | 54 |
DC8015#24H | B.S | 24 | 14.0~27.6 | 0.08 | 1.92 | 3100 | 33.55 | 0.95 | 0.138 | 3.5 | 33 | 54 |
