General Specification
Frame / Impeller: Plastic
Lead Wire: AWG#24 or Equivalent (+)Red, (-)Black
Ball Bearing 50,000Hrs(40°C)
Sleeve Bearing 30,000Hrs(40°C)
Operating temperature: -10°C~+70°C
Storage temperature: -40°C~+70°C
Art. No. | # Bearing Type | Rated Voltage (VDC) | Operating Voltage (VDC) | Input Current (A) | Input Power (W) | Speed (RPM) | Max Air Volum | Max Static Pressure | Noise (dB-A) | Weight (g) | ||
(CFM) | m3/min | Inch-H2O | mm-H2O | |||||||||
DC8038#12L | B | 12 | 7.0~13.8 | 0.2 | 2.4 | 3400 | 45.2 | 1.28 | 0.281 | 7.13 | 43 | 153 |
DC8038#12M | B | 12 | 7.0~13.8 | 0.38 | 4.56 | 4200 | 57.21 | 1.62 | 0.424 | 10.77 | 47 | 153 |
DC8038#12H | B | 12 | 7.0~13.8 | 0.9 | 10.8 | 5700 | 80.16 | 2.27 | 0.812 | 20.63 | 53 | 153 |
DC8038#24L | B | 24 | 14.0~27.6 | 0.15 | 3.6 | 3400 | 45.2 | 1.28 | 0.281 | 7.13 | 43 | 153 |
DC8038#24M | B | 24 | 14.0~27.6 | 0.24 | 5.76 | 4200 | 57.21 | 1.62 | 0.424 | 10.77 | 47 | 153 |
DC8038#24H | B | 24 | 14.0~27.6 | 0.5 | 12 | 5700 | 80.16 | 2.27 | 0.812 | 20.63 | 53 | 153 |
DC8038#48L | B | 48 | 28.0~56.0 | 0.08 | 3.84 | 3400 | 45.2 | 1.28 | 0.281 | 7.13 | 43 | 153 |
DC8038#48M | B | 48 | 28.0~56.0 | 0.11 | 5.28 | 4200 | 57.21 | 1.62 | 0.424 | 10.77 | 47 | 153 |
