General Specification
Frame / Impeller: Plastic
Lead Wire: AWG#28 or Equivalent (+)Red, (-)Black
Ball Bearing 50,000Hrs(40°C)
Sleeve Bearing 30,000Hrs(40°C)
Operating temperature: -10°C~+70°C
Storage temperature: -40°C~+70°C
Art. No. | # Bearing Type | Rated Voltage (VDC) | Operating Voltage (VDC) | Input Current (A) | Input Power (W) | Speed (RPM) | Max Air Volum | Max Static Pressure | Noise (dB-A) | Weight (g) | ||
(CFM) | m3/min | Inch-H2O | mm-H2O | |||||||||
DC3010#05L | B.S | 5 | 3.5~5.5 | 0.07 | 0.35 | 6000 | 2.37 | 0.067 | 0.04 | 1 | 26 | 10 |
DC3010#05D | B.S | 5 | 3.5~5.5 | 0.11 | 0.55 | 7500 | 3 | 0.09 | 0.06 | 1.5 | 22 | 10 |
DC3010#05M | B.S | 5 | 3.5~5.5 | 0.16 | 0.09 | 9000 | 3.53 | 0.1 | 0.1 | 2.5 | 29 | 10 |
DC3010#12L | B.S | 12 | 7.0~13.8 | 0.05 | 0.6 | 6000 | 2.37 | 0.067 | 0.04 | 1 | 26 | 10 |
DC3010#12M | B.S | 12 | 7.0~13.8 | 0.07 | 0.84 | 7500 | 3 | 0.09 | 0.06 | 1.5 | 29 | 10 |
DC3010#12H | B.S | 12 | 7.0~13.8 | 0.09 | 1.08 | 9000 | 3.53 | 0.1 | 0.1 | 2.5 | 32 | 10 |
