General Specification
Frame / Impeller: Plastic
Lead Wire: AWG#24 or Equivalent (+)Red, (-)Black
Ball Bearing 50,000Hrs(40°C)
Sleeve Bearing 30,000Hrs(40°C)
Operating temperature: -10°C~+70°C
Storage temperature: -40°C~+70°C
Art. No. | # Bearing Type | Rated Voltage (VDC) | Operating Voltage (VDC) | Input Current (A) | Input Power (W) | Speed (RPM) | Max Air Volum | Max Static Pressure | Noise (dB-A) | Weight (g) | ||
(CFM) | m3/min | Inch-H2O | mm-H2O | |||||||||
DC5015#05D | B.S | 5 | 3.5~5.5 | 0.15 | 0.75 | 4000 | 9.89 | 0.28 | 0.126 | 3.2 | 25 | 29 |
DC5015#05L | B.S | 5 | 3.5~5.5 | 0.22 | 1.1 | 4800 | 12.36 | 0.35 | 0.181 | 4.6 | 27 | 29 |
DC5015#05M | B.S | 5 | 3.5~5.5 | 0.32 | 1.6 | 5500 | 13.29 | 0.4 | 0.24 | 6.1 | 31 | 29 |
DC5015#12L | B.S | 12 | 7.0~13.8 | 0.06 | 0.72 | 4000 | 9.89 | 0.28 | 0.126 | 3.2 | 27 | 29 |
DC5015#12M | B.S | 12 | 7.0~13.8 | 0.08 | 0.96 | 4800 | 12.36 | 0.35 | 0.181 | 4.6 | 31 | 29 |
DC5015#12H | B.S | 12 | 7.0~13.8 | 0.1 | 1.2 | 5600 | 14.13 | 0.4 | 0.24 | 6.1 | 34 | 29 |
DC5015#12U | B.S | 12 | 7.0~13.8 | 0.13 | 1.56 | 6400 | 16.24 | 0.46 | 0.315 | 8 | 36 | 29 |
DC5015#24D | B.S | 24 | 14.0~27.6 | 0.05 | 1.2 | 4000 | 9.89 | 0.28 | 0.126 | 3.2 | 25 | 29 |
DC5015#24L | B.S | 24 | 14.0~27.6 | 0.06 | 1.44 | 4800 | 12.36 | 0.35 | 0.181 | 4.6 | 27 | 29 |
DC5015#24M | B.S | 24 | 14.0~27.6 | 0.07 | 1.68 | 5600 | 14.13 | 0.4 | 0.24 | 6.1 | 31 | 29 |
DC5015#24U | B.S | 24 | 14.0~27.6 | 0.08 | 1.92 | 6400 | 16.24 | 0.46 | 0.315 | 8 | 36 | 29 |
