• Large convection surface
• Clip fixing
• Ready for use
• Maintenance free
Compact convection heater for use in areas with explosion hazard for prevention of formation of condensation, temperature fluctuations and for protection against frost in transmitter housings, switch cabinets and measuring equipment.
Technical Data
CREx 020 | |
Heating element | high performance cartridge |
Heater body | aluminium profile, silver anodised |
Connection | Si HF-JZ 3×0.5mm² cable, length 1m |
Connection PE | 4mm² |
Mounting | clip for 35mm DIN rail, EN 60715 |
Fitting position | vertical airflow (connection on bottom) |
Storage temperature | -45 to +70°C (-49 to +158°F) |
Operating/Storage humidity | max. 90% RH (non-condensing) |
Protection type/Protection class | IP65/I(earthed) |
¹ Operating with voltages below 140V AC/DC reduces heating performance by approx. 10%.
Art. No. | Heating capacity | Operating voltage | Length (L) | Weight (approx.) |
02010.0-00 | 50W | 230-240VAC | 150mm | 1.3kg |
02011.0-00 | 100W | 230-240VAC | 180mm | 1.5kg |
02012.0-00 | 150W | 230-240VAC | 180mm | 1.5kg |
02013.0-00 | 400W | 230-240VAC | 180mm | 1.5kg |
02010.0-01 | 50W | 110-120VAC | 150mm | 1.3kg |
02011.0-01 | 100W | 110-120VAC | 180mm | 1.5kg |
02012.0-01 | 150W | 110-120VAC | 180mm | 1.5kg |
02013.0-01 | 400W | 110-120VAC | 180mm | 1.5kg |
